Descriere:
The PDI spirometry software allows
you to perform in real time a complete spirometry with:
The software includes also a series of paediatric incentive animations.
User
friendly and easy “Report Designer”
As far as report documentation is concerned, you will be supported by the new MEC PFT Report Server program, which provides you several handy report tools on the basis on which you can clearly structure and tailor each reporting to your individual needs and integrate your headings and hospital or practice logos. MEC PFT report can be evaluated on screen before printed on paper and/or forwarded by email. The reports may be designed directly in Microsoft Word and saved as Word documents or as Acrobat PDF format. Of course the results may be exported to medical files (HIS) with protocols like XML, TXT, HL7 etc..
Automatic
Lung Function Interpretation software “ALFI”
Guidelines GINA and GOLD classifications are integrated for desease
classification.
The ALFI software is yearly updated and may be downloaded from our
website but of course you can also use your own predicted equations and edit
the standard interpretation software algorithms making this piece of software a
very useful tool for research applications.
Flow measurement |
Variable orifice membrane |
Range |
±0.02 – ±20l/s |
Accuracy |
0.05 – 15l/s ±2% |
Resistance |
< 0.01 kPa/(l/s) at 10 l/s |
Resolution |
< 5ml |
Back pressure |
<0.93kPa at 14l/s |
Volume
determination |
digital integration |
Range |
0 - ± 20 l/s |
Accuracy |
5 ml |
Mouth pressure |
N/A |
Range |
N/A |
Accuracy |
N/A |
Temperature :
|
+10°C
to +40°C. |
Barometric pressure |
850
to 1200 mbar |
Humidity |
25
– 85% (non condensing) |
PC
minimal requirements |
Pentium IV 3 GHz or higher,
Windows 2000, XP SP2 or Vista with 500 Mb RAM or more, 800*600 display
with true colours (32 Bit), CD-Drive, Keyboard, mouse and graphics printer,
at least 1 USB 2 port, Microsoft Office Word® 2000 or higher |
